304SST Electronic Pressure Sensor Piezoresistive Oil Filled ODM

Product Categories

Hefei WNK Smart Technology Co.,Ltd

Contact Now

Name: 304SST Electronic Pressure Sensor Piezoresistive Oil Filled ODM
Brand: WNK, WNK
Price: 10.00 USD

Brand Name : WNK, WNK

Model Number : WNK80MA, WNK811-1

Certification : CE, ROHS

Place of Origin : Anhui, China

Price : $10.00 - $35.00/Pieces

Supply Ability : 2000 Set/Sets per Week

Packaging Details : each product in one inner paper box with protection

Warranty : 1 YEAR

Customized support : OEM, ODM

Measured media : liquid, gas and steam

Output signals : 4~20mA, 1-5V, 0-5V, 0-10V, 0.5V-4.5V, I2C

Accuracy : 0.2%F.S, 0.5%F.S

Pressure range : -100kPa~0, 0-10kPa, 100kPa, 1MPa, 5MPa, 10MPa, 20MKPa, 50MPa

Protection class : IP65

Housing material : 304SST

Power Supply : 24VDC/12VDC/5VDC/3.3V

Electrical connection : Cable outlet, connector

Port : Shanghai port

Contact Now

Product Spec

WNK811 diffused silicon oil filled pressure sensor with customization
Applicable media	Liquid, Gas
Pressure range	-100kPa, 10kPa, 35kPa, 70kPa, 100kPa, 250kPa, 400kPa, 600kPa,1MPa, 1.6MPa, 2.5MPa, 4MPa, 6MPa, 10MPa, 16MPa, 25MPa, 40MPa, 60MPa(bar and psi unit available)
Pressure measurment	Gauge Pressure, Absolute pressure, Sealing pressure
Output	4-20mA/0.5-4.5V/1 -5V/0-5V/0-10V/I2C
Accuracy(linearity,Hysteresis and Repeatability)	0.5%F.S.(Typical)
Power supply	24VDC/12VDC/5VDC/3.3V
Compensation temperature	-20~85ºC
Ambient temperature	-40~125ºC
Working temperature	-40~125ºC
Temperature drift(zero)	±0.15% F.S. (-20~85ºC)
Temperature drift(full range)	±0.15% F.S. (-20~85ºC)
power(electrical) connect	Customization Connector, Cable outlet
Mechanical connection	G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize
Housing material	304 stainless steel(inner core is 316 stainless steel)
Protection	IP65

Process Connection

About us

1. 100% of all products we do temperature compensation and aging test before shipment.

2. Our products are all calibrated and shipped with certificate.

FAQ

Contact

Product Tags:

304SST Oil Filled Pressure Transducer
